Good Mechanical Property HDGL Galvalume Steel Coil With ASTM Standard
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProducts Name | Galvanized Steel Coil | Grade | DX51D, SGCC, SGHC,SPCC,SGHC, DX51D,SGCC. |
---|---|---|---|
Certification | ISO,SGS,BV,etc. | Brand | HY Metal |
Processing Service | Decoiling, Cutting | Standard | AiSi, ASTM, Bs, DIN, GB, JIS |
Highlight | hdgl galvalume steel coil,hdgl galvalume steel coils,astm standard galvalume steel coil |
Goold Mechanical Property Galvalume Steel Coil With ASTM Standard , Long Life Span
Place of Origin | JiangSu, China |
---|---|
Brand Name | HY METAL |
Certification | CE & SGS |
Minimum Order Quantity | 25 MT |
Price | US $700/MT -- US $900/MT |
Packaging Details | Standard seaworthy packing for international delivery |
Delivery Time | 15-30 Days |
Payment Terms | T/T or L/C |
Supply Ability | 10000 MT per Month |
Name | Galvalume Coil | Grade | CS Type B,type C |
---|---|---|---|
Thickness | 0.15-1.5mm | Place Of Origin | Jiangsu, China |
Brand Name | HY METAL | Type | Steel Coil |
High Light |
galvalume steel coil,galvalume steel galvalume steel |
Goold Mechanical Property Galvalume Steel Coil With ASTM Standard , Long Life Span
Quick Details
- Technique:Cold Rolled
- Surface Treatment:Galvalume
- Application:Construction & Base Metal
- Width:600-1250mm
- Length:Steel Coil
- Description:HDGL
- Base Metal:CS
- Available Dipped Layers:50-275G/M2
- Inner Diameter:508-610mm
- Available Surface Treatment:Passivating & Oiling & AFP & Filming
- HS Code:72106100
- Approved Certificate:CE & SGS
Specifications
HDGL
1. High Corrosion Resistance
2. Highly Decorative
3. Long Life Span
HDGL
Brief Introduction
The HDGL is a kind of coated steel coil/sheet. With the cold rolled steel of different strength and thickness as substrate, it is produced through applying Al-Zn coat on both faces by hot dip process. In its coating, Al accounts for about 55%, Si 1.6%, while the remaining is Zn. It enjoys both the physical protective feature and durability of Al and the electrochemical protective property of Zn. And its surface has bright silver color and regular embossed-like figure, which are highly decorative.
Specification
1. Thickness: 0.15-1.5mm
2. Width: 600-1250mm
3. Inner Diameter: 508mm
4. Weight of Steel Coil: 3-15MT
5. Coating Type: Al-Zn Alloy
6. Available Dipped Layer: 50-275g/m2
7. Surface Finish Structure: Regular Spangle & Small Spangle & Zero Spangle
8. Available Surface Treatment: Passivating & Oiling & AFP & Filming
Mechanical Properties
Grade | Tension Test | ||
Yield Strength (MPa) | Tensile Strength (MPa) | Elongation% No Less Than | |
A80mm | |||
CS type B type C | -- | <500 | 22-24 |
DS | <300 | <420 | 24-26 |
255 | >250 | >320 | 22 |
345 Class1 | >350 | >420 | 14 |
550 | >550 | >570 | -- |
Application
1. Architecture Roofs and outside walls of civilian and industrial buildings, garage doors, fencings and window blinds
2. Appliances Industry Outer clad sheets for washing machine, refrigerator, television, air conditioner and ventilation system, explosion-proof strip, solar water heater and appliance parts
3. Auto Industry Muffler, heat shields of exhaust pipe and catalytic converter, auto parts & accessories under the frame, signboard in highway
4. Industrial Instruments Electric control cabinet, industrial refrigeration equipment, automatic vending machine
