Hot Dipped Electro Galvanized Steel Coil AZ120 DX51D+AZ

Place of Origin Jiangsu, CN
Brand Name Haiyue / HY METAL
Certification ISO9001
Minimum Order Quantity 5 Tons
Price negotiable
Packaging Details Customized packaging
Delivery Time 30 days
Payment Terms L/C, T/T, Western Union
Supply Ability 10000 Ton/Tons per Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Products Name Galvanized Steel Coil Grade DX51D, SGCC, SGHC,SPCC,SGHC, DX51D,SGCC.
Certification ISO,SGS,BV,etc. Brand HY Metal
Processing Service Decoiling, Cutting Standard AiSi, ASTM, Bs, DIN, GB, JIS
Highlight

electro galvanized steel coil az120

,

hot dipped electro galvanized steel coil

,

az120 hot dip galvanized steel strip

Leave a Message
Product Description

Hot Dipped Galvalume Steel Coils AZ120 , DX51D+AZ Highly Decorative , EN



Place of Origin JiangSu, China
Brand Name Haiyue
Certification CE & SGS
Minimum Order Quantity 25 MT
Price US $700/MT -- US $900/MT
Packaging Details Standard seaworthy packing for international delivery
Delivery Time 15-30 Days
Payment Terms T/T or L/C
Supply Ability 10000 MT per Month



PRODUCT DETAILS
Name Galvalume Steel Coil Standard ASTM,EN,JIS
Grade DX51D+AZ Thickness 0.15-1.5mm
Place Of Origin Jiangsu, China (Mainland) Brand Name Haiyue
Model Number DX51D+AZ Type Steel Coil
High Light

Galvalume Steel Coils

,

galvalume steel galvalume steel



PRODUCT DESCRIPTION



Hot Dipped Galvalume Steel Coils AZ120 , DX51D+AZ Highly Decorative , EN



Quick Details

  • Technique:Cold Rolled
  • Surface Treatment:Galvalume
  • Application:Construction & Base Metal
  • Width:600-1250mm
  • Length:Steel Coil
  • Description:HDGL
  • Base Metal:DC01
  • Available Dipped Layers:50-275G/M2
  • Inner Diameter:508-610mm
  • Available Surface Treatment:Passivating & Oiling & AFP & Filming
  • HS Code:72106100
  • Approved Certificate:CE & SGS

Specifications

HDGL
1. High Corrosion Resistance
2. Highly Decorative
3. Long Life Span
HDGL
Brief Introduction
The HDGL is a kind of coated steel coil/sheet. With the cold rolled steel of different strength and thickness as substrate, it is produced through applying Al-Zn coat on both faces by hot dip process. In its coating, Al accounts for about 55%, Si 1.6%, while the remaining is Zn. It enjoys both the physical protective feature and durability of Al and the electrochemical protective property of Zn. And its surface has bright silver color and regular embossed-like figure, which are highly decorative.

Mechanical Properties

Grade Tension Test
Yield Strength (MPa) Tensile Strength (MPa) Elongation% No Less Than
A80mm
DX51D+AZ -- <500 22-24
DX52D+AZ <300 <420 24-26
S250GD+AZ >250 >320 22
S350GD+AZ >350 >420 14
S550GD+AZ >550 >570 --


Application
1. Architecture Roofs and outside walls of civilian and industrial buildings, garage doors, fencings and window blinds
2. Appliances Industry Outer clad sheets for washing machine, refrigerator, television, air conditioner and ventilation system, explosion-proof strip, solar water heater and appliance parts
3. Auto Industry Muffler, heat shields of exhaust pipe and catalytic converter, auto parts & accessories under the frame, signboard in highway
4. Industrial Instruments Electric control cabinet, industrial refrigeration equipment, automatic vending machine
Superiority
1. Resistance to Corrosion Has better performance in corrosion resistance than hot dip galvanized coil/sheet of the same thickness and its service life is 1-5 times longer than general hot dip galvanized coil/sheet.
2. Machinability Can satisfy the processing requirements of rolling, coiling and others processes alike.
3. Thermal Resistance Can sustain the environment at 315°C for long time.
4. High Reflectivity Reflection ability of heat and light is twice as much as those of hot dip galvanized steel coil/sheet, and its reflectivity is more than 0.75, exceeding 0.65 (required by the EPA Energy Star Standard), which is an ideal construction material of saving energy
