JIS SGCCHot Dip Galvanized Steel Roll For Profile / Section 600mm-1500mm Width
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Galvanized Steel Coil | Grade | DX51D, SGCC, SGHC,SPCC,SGHC, DX51D,SGCC. |
|---|---|---|---|
| Certification | ISO,SGS,BV,etc. | Brand | HY Metal |
| Processing Service | Decoiling, Cutting | Standard | AiSi, ASTM, Bs, DIN, GB, JIS |
| Highlight | 600mm-1500mm galvanized steel roll,600mm-1500mm galvanized steel coil roll,sgcc galvanized steel roll |
||
Product Description
jis hot dip galvanized steel coil for profile / section , 600mm - 1500mm width
| Place of Origin | China (Mainland) |
|---|---|
| Brand Name | Haiyue |
| Certification | CE & SGS |
| Minimum Order Quantity | 25 MT |
| Price | US $ 600-800 / MT |
| Packaging Details | Standard seaworthy packing for international delivery |
| Delivery Time | 10-30 days |
| Payment Terms | T/T or L/C |
| Supply Ability | 10000 Ton/Tons per Month |
PRODUCT DETAILS
| Name | Galvanised Steel Coil | Width | 600mm - 1500mm |
|---|---|---|---|
| Grade | SGCC | Place Of Origin | China (Mainland) |
| High Light |
galvanized steel roof panels,stainless steel galvanized steel |
||
PRODUCT DESCRIPTION
JIS Standard Hot Dip Galvanized Steel Coil For Profile / Section , 600mm - 1500mm Width
Quick Details
- Thickness:0.15-4.0mm
- Brand Name: Sincere
- Model Number:SGCC
- Type:Steel Coil
- Technique:Cold Rolled
- Surface Treatment:Galvanized
- Application:Construction & Base Metal
- Width:600-1500mm
- Length:Steel Coil
- Description:Galvanized Steel Coil
- Base Metal:SPCC
- Available Dipped Layers:50-275g/m2
- Inner Diameter:508-610mm
- Available Surface Treatment:Passivating & Oiling & AFP & Filming
- HS Code:72104900
- Approved Certificate:CE & SGS
- Specification
-
1. Thickness: 0.15-4.0mm
2. Width: 600-1500mm
3. Inner Diameter: 508mm
4. Weight of Steel Coil: 3-18MT
5. Coating Type: Pure Zinc
6. Available Dipped Layer: 50-275g/m2
7. Surface Finish Structure: Zero Spangle & Finishing Small Spangle & Regular Spangle
8. Available Surface Treatment: Passivating & Oiling & AFP & Filming
-
Mechanical Properties
Grades
Mechanical Property
Coating Adhesion
Yield StrengthMPa
Tensile StrengthMPa
Elongation%
≥
Bending Center Diameter at Following Coating Weight (g/m²) (a=Plate Thickness)
La=80mm b=20(mm)
At Following nominal Thickness ( mm)
≤0.7
>0.7
≤140/140
>140/140-175/175
>175/175
SGCC SGHC
140-350
270-500
20
22
0a
1a
2a
SGCD1
140-300
270-420
24
26
0a
1a
2a
SGCD2 SGCD3
140-260
270-380
28
30
0a
1a
2a
- Our company was formed by a group of steel experts who wish to offer their vast experience in flat steel to clients all over the world. We are mainly dealing with all items of flat steel, and coated products such as galvanized steel are our expertise. Our aim is to help our clients find the best solution for their steel needs and other products needs.
We have the very professional steel mill to supply you different kinds of steel coil. And we also supply export and OEM service
