Anti Corrosion Hot Dipped Galvanized Steel Coil With BS Standard
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Galvanized Steel Coil | Grade | DX51D, SGCC, SGHC,SPCC,SGHC, DX51D,SGCC. |
|---|---|---|---|
| Certification | ISO,SGS,BV,etc. | Brand | HY Metal |
| Processing Service | Decoiling, Cutting | Standard | AiSi, ASTM, Bs, DIN, GB, JIS |
| Highlight | anti corrosion hot dipped galvanized steel coil,anti corrosion hot dip galvanized steel coil,bs standard hot dip galvanized steel coil |
||
Product Description
High Anti-Corrosion Hot Dip Galvanized Steel Coil With BS Standard
| Place of Origin | China (Mainland) |
|---|---|
| Brand Name | Haiyue |
| Certification | CE & SGS |
| Minimum Order Quantity | 25 MT |
| Price | US $ 600-800 / MT |
| Packaging Details | Standard seaworthy packing for international delivery |
| Delivery Time | 10-30 days |
| Payment Terms | T/T or L/C |
| Supply Ability | 10000 Ton/Tons per Month |
PRODUCT DETAILS
| Name | Gi Steel Coil | Payment | T/T Or L/C |
|---|---|---|---|
| Name2 | Galv Sheet And Coil | Name3 | Gi Sheet Coil |
| High Light |
galvanized steel roof panels,stainless steel galvanized steel |
||
PRODUCT DESCRIPTION
High Anti-Corrosion Hot Dip Galvanized Steel Coil With BS Standard
Quick Details
High Anti-Corrosion Galvanized Steel
Brief Introduction
Galvanized Steel Coil gets coated in layers of zinc because rust won't attack this protective metal. The most external layer is all zinc, but successive layers are a mixture of zinc and iron, with an interior of pure steel. These multiple layers are responsible for the amazing property of the metal to withstand corrosion-inducing circumstances. Zinc also protects the steel by acting as a "sacrificial layer." If rust does take hold on the surface of Galvanized Steel Coil, the zinc will get corroded first. This allows the zinc that is spread over the breach or scratch to prevent rust from reaching the steel. For countless outdoor, marine, or industrial applications, Galvanized Steel Coil is an essential fabrication component.
The Protection Principle
1. Anodic reaction: Zn-2e=Zn2+
(The alloy coating loses electron, sacrificing itself in dissolution.)
2. Cathodic reaction: Fe2++2e=Fe
(Fe gains electron reaction, being protected)
Specification
1. Thickness: 0.15-4.0mm
2. Width: 600-1500mm
3. Inner Diameter: 508mm
4. Weight of Steel Coil: 3-18MT
5. Coating Type: Pure Zinc
6. Available Dipped Layer: 50-275g/m2
7. Surface Finish Structure: Zero Spangle & Finishing Small Spangle & Regular Spangle
8. Available Surface Treatment: Passivating & Oiling & AFP & Filming
Mechanical Properties
| Grades | Mechanical Property | Coating Adhesion | |||||
| Yield StrengthMPa | Tensile StrengthMPa |
Elongation% ≥ |
Bending Center Diameter at Following Coating Weight (g/m²) (a=Plate Thickness) | ||||
| La=80mm b=20(mm) | |||||||
| At Following nominal Thickness ( mm) | |||||||
| ≤0.7 | >0.7 | ≤140/140 | >140/140-175/175 | >175/175 | |||
| SGCC SGHC | 140-350 | 270-500 | 20 | 22 | 0a | 1a | 2a |
| SGCD1 | 140-300 | 270-420 | 24 | 26 | 0a | 1a | 2a |
| SGCD2 SGCD3 | 140-260 | 270-380 | 28 | 30 | 0a | 1a | 2a |
Application
1. Architecture Roofs and outside walls of civilian and industrial buildings, garage doors, fencings and window blinds
2. Appliances Industry Outer clad sheets for washing machine, refrigerator, television, air conditioner and ventilation system, explosion-proof strip, solar water heater and appliance parts
3. Auto Industry Muffler, heat shields of exhaust pipe and catalytic converter, auto parts & accessories under the frame, signboard in highway
4. Industrial Instruments Electric control cabinet, industrial refrigeration equipment, automatic vending machine
Our customers all over the world, products are mainly exported to Germany, Greece, Finland, Hungary and Russia and other European countries, north American countries such as America, Canada, Colombia, Peru and Brazil and other Latin American countries.Asian countries such as India, Ukraine and dubai.Southeast Asian countries such as Thailand, Vietnam, Philippines and Singapore.Ghana, somalia, South Africa and other African countries.
